Flux gel EO-B-001
Flux gel for repair work on PCB
- For large quantities - ask for quotation
- sales@etronix.se
- BrandEmil Otto
- Flux classORL0
- SKU4691
- Solid contentVery high
Description
Article no.: 504691
Description
The flux gel EO-B-001 was specially developed for repair work on printed circuit boards and is characterised by high activity and very good wetting and spreading behaviour. Due to these properties, the paste is extremely economical to dose. The paste is applied via plastic tips, which enable precise dosing and positioning of the paste and offer the advantage over steel needles that the printed circuit boards cannot be scratched. The flux paste can be processed with hot air- and soldering irons.
- Perfect soldering results
- Economical consumption
- Also contaminated pads and pins are activated
- Careful and targeted dosage
- Broad process window (very high thermal stability, very good activity over long interval)
- High-viscosity paste with which SMD components can be soldered extremely well due to their temperature stability
| Application area: | Manual-, repair- and dip soldering, special applications, suitable for SMD-components as well as SnPb and Pb-free alloys |
| Appearance: | pasty, amber, opaque, waxy, mild |
| Solids content: | very high Gew.-% |
| Density at 20 °C: | 0.9–1.0 g/ml |
| Activators: | di-carboxylic acids, synthetic resin, halogen-free |
| Flash point: | >80 °C |
| Viscosity (DIN 51810-1): | high |
| Durability: | 12 months |
